All-in-One Solar Street Light — 100W
A fully integrated solar street light that combines a monocrystalline solar panel, LiFePO4 battery, MPPT controller, and high-efficiency LED into one compact, IP65-rated unit. No trenching, no cabling — just bolt it to the pole and it runs off-grid from day one.
Technical Specifications
Full engineering data for the TH-SSL-AIO-100W — LED output, solar panel, battery, controller, physical build, and certifications.
| Specification | Value |
|---|---|
| LED Light Source | |
| Power | 100 W |
| Luminous Flux | 16,000 lm |
| Efficacy | 160 lm/W |
| Color Temperature | 5000K (Cool White) |
| CRI | 70+ |
| Lifespan | 50,000 h |
| Solar Panel | |
| Type | Monocrystalline Silicon |
| Power | 100 W |
| Efficiency | 22% |
| Lifespan | 25 years |
| Battery | |
| Type | LiFePO4 (Lithium Iron Phosphate) |
| Capacity | 512 Wh |
| Cycles | 2000+ (@ 80% DOD) |
| Operating Temperature | -20°C to 60°C |
| Controller | |
| Type | MPPT (Maximum Power Point Tracking) |
| Charging Efficiency | 99% |
| Smart Dimming | Auto half-power at midnight |
| Motion Sensor | Optional (radar, full-brightness trigger) |
| Physical | |
| Material | ADC12 Die-Cast Aluminum |
| IP Rating | IP65 |
| Wind Resistance | 130 km/h |
| Mounting Height | 6 – 9 m |
| Pole Diameter | 60 – 76 mm |
| Certification | |
| Standards | CE · RoHS · IP65 · IK08 |
| Warranty | 5 years (LED, battery, panel, controller) |
Key Features
Engineered for off-grid reliability — every component is sized and protected for years of unattended outdoor service.
All-in-One Design
Solar panel, battery, LED, and controller integrated into a single compact unit — fast, tool-light installation with no external wiring.
LiFePO4 Battery
2000+ cycles with safe lithium iron phosphate chemistry that keeps delivering even at -20°C — far safer and longer-lived than lead-acid.
MPPT Controller
99% charging efficiency versus ~75% for PWM controllers — harvests more energy on cloudy days and charges the battery faster.
Smart Dimming
Automatic half-power at midnight extends battery life and runtime. Motion-sensor ready for full brightness only when it's needed.
IP65 + IK08
Waterproof and impact-resistant die-cast aluminum housing built for harsh outdoor and industrial environments — dust, rain, and vandalism.
5-Year Warranty
Full coverage across the LED, battery, solar panel, and controller — backed by factory-direct engineering support and fast shipping.
Where to Use This Light
Recommended mounting height and pole spacing for each application — size your exact layout with our Solar Street Light Calculator.
Parking Lots
Even, glare-free illumination across large open bays and aisles for safer vehicle and pedestrian flow after dark.
Height 8–9 m · Spacing 25–30 mRural Roads
Off-grid lighting where trenching and grid connection are impractical or too expensive to run.
Height 6–7 m · Spacing 20–25 mIndustrial Parks
Durable IP65 build shrugs off dust, vibration, and temperature swings in heavy-duty industrial environments.
Height 7–9 m · Spacing 25–30 mCommunity Spaces
Safe, comfortable lighting for parks, plazas, and walkways without light pollution or high running costs.
Height 6–8 m · Spacing 20–25 mCalculate Your Savings
Solar street lights carry zero electricity bills and skip the cost of trenching, cabling, and grid connection. For most projects the TH-SSL-AIO-100W pays for itself against grid lighting in roughly three years — then runs free for the rest of its 50,000-hour life.
Plan your project numbers
